商品介绍

• 商品信息

• 出版社： 机械工业出版社

• 商品名称：图解车工/数控车工快速入门

• 作者：[美]皮特·霍夫曼（Peter Hoffman）[美]埃里克·霍普韦尔（Eric Hopewell）等

• 市场价：59.8

• ISBN号：9787111612681

• 版次：1-1

• 出版日期：2019-04

• 页数：159

• 字数：277

本书采用通俗易懂的语言，介绍了车削加工和数控车削加工所需掌握的基本知识和技能。本书主要内容包括：车床概述、车床上工件夹紧和刀具夹紧设备、车床操作、手动车螺纹、锥面车削、数控加工基础、数控车削简介、数控车削编程、数控车削的设置与操作。

目　　录
出版说明
序

第
1章　车床概述 ···························· 1

1.1　概述 ·············································· 2

1.2　主轴箱 ··········································· 2
1.2.1　主轴 ········································ 2
1.2.2　变速箱
····································· 5

1.3　床身 ·············································· 5

1.4　溜板 ·············································· 5
1.4.1　床鞍 ········································ 5
1.4.2　丝杠和光杠
······························· 7
1.4.3　溜板箱
····································· 7

1.5　尾座 ·············································· 8

1.6　车床规格 ········································ 8
1.6.1　回转直径 ·································· 8
1.6.2　床身长度 ·································· 9

第
2章　车床上的工件夹紧和刀具
夹紧设备 ··························· 10

2.1　概述············································· 11

2.2　工件夹紧······································· 11
2.2.1　卡盘 ······································· 11
2.2.2　夹头 ·······································15
2.2.3　花盘 ·······································18
2.2.4　工件在两个顶尖之间夹紧·············18
2.2.5　心轴 ·······································22
2.2.6　工件的辅助支承方法···················23

2.3　刀具夹紧·······································25
2.3.1　摆杆式刀具夹紧·························25
2.3.2　快换式刀具夹紧·························26
2.3.3　可转位刀架
······························27
2.3.4　孔加工刀具夹紧·························28

第
3章　车床操作 ··························· 29

3.1　概述·············································30

3.2　背吃刀量、切削速度、进给量和加工工时

的计算·········································· 30
3.2.1　背吃刀量 ································· 30
3.2.2　切削速度 ································· 31
3.2.3　进给量
···································· 31
3.2.4　粗加工与精加工························· 31
3.2.5　加工工时的计算························· 32

3.3　通用车床操作安全事项 ····················· 32

3.4　端面车削和外圆车削 ························ 33
3.4.1　端面车削和外圆车削刀具············· 33
3.4.2　刀具的基本几何参数··················· 35
3.4.3　端面车削 ································· 41
3.4.4　外圆车削 ································· 46
3.4.5　轴肩车削 ································· 49

3.5　锉削与抛光 ···································· 54

3.6　中心孔钻与定点钻 ··························· 56
3.6.1　中心孔钻 ································· 56
3.6.2　定点钻
···································· 56

3.7　车床上的孔加工 ······························ 57
3.7.1　钻孔 ······································· 57
3.7.2　铰孔 ······································· 58
3.7.3　加工沉头孔和埋头孔··················· 58
3.7.4　镗孔 ······································· 58
3.7.5　加工内轴肩
······························ 60

3.8　使用丝锥和板牙加工螺纹 ·················· 61
3.9　成形加工 ······································· 61
3.10
